1000W Professional Long Range FM Radio Transmitter, 1000Watt FM Radio Broadcast
2.263,40$
- Alarm and protection of over-current,over-voltage,over-temperature, overpower and standing wave ratio improve the transmitter warning mechanism
- 0W - 1000W continuously adjustable transmit power can meet a variety of different frequency modulation demand
- User-friendly digital LCD panel, using one rotary knob to control.
- 1U 19-inch thickened all-aluminum case, strong and excellent heat dissipation.
- The powerful digital processing technology can create a perfect CD-like hearing effect for you
Technical Specifications
1. Frequency Range: 88.1-107.9MHZ, Frequency Setting step：10KHz
2.Carrier Frequency precision：±200Hz
3. Residual Wave Radiation：≥65dBc
4.Audio Input Impedance：600Ω,Balance
5.Separation：60dB Pilot Signal Modulation：8%~10%
6.Audio Input Level：±10dBm,step 0.01dB
7. S/N：≥75dB(30H~15kHz,100%)
8. Audio Harmonic Distortion：<0.05%
9.Audio response： ±0.05dB(30Hz~15KHz)
10.Output Load Impedance：50Ω
11.Output Power：0~1000W
12.Pre-emphasis：0μS,50μS,75μS
13.Deviation：±75kHz
14.Pilot Frequency：19 kHz±1Hz
15.Sub-carrier Suppression：≥65dB
Feature
· Built-in audio signal limiter
· Analog and Digital (AES/EBU) audio signal input directly
· AGC circuit can keep the Output Power stability
· Big LCD display all the parameters in real time
· Communication Interface by RS232 for remote
· Five kinds of protections for the security
· Compact structure
· Stainless steel cabinet
Outstanding features
1) OVERHEAT PROTECTION: The transmitter will switch to auto-protection with alarm message and a beep sound once the working temperature gets higher than normal range.
2) OVER SWR PROTECTION: SWR is the indication of antenna system connection with transmitter. Once the connection is bad and causing a high SWR Value, the transmitter will switch to automatic protection mode by showing alarm message on the screen with a beeping sound meanwhile.
3) FAN ERROR ALARM When the fan stops running, the alarm message will be displayed on the screen.
4) ADJUSTABLE POWER OUTPUT The RF out of this 1000w FM transmitter is continuously adjustable from 0-1000watt at the stepping of 0.1watt, with just one transmitter you’ll get multiple modes of outputs and easy to tune as per your needs.
Package Include
One 1000W FM Transmitter
One audio line
One power line
